Woods Lamp Skin Detection

Overview:Wood's lamp is a UV light device dedicated to skin testing. By irradiating the skin with specific wavelengths of ultraviolet light, it can help to observe skin conditions such as pigmentation, fungal infections, abnormal oil secretion and so on. It is widely used in the fields of cosmetology, skin care and medical testing.
Contact
  • Product introduction
  • Technical parameter
  • Product specification
  • This Wood's lamp uses a high-quality UV light source for accurate detection and can visualize the hidden problems under the skin.

    Its lightweight design makes it easy to carry and operate, suitable for beauty salons, dermatology clinics and personal care. Through

    the fluorescent reaction of the Wood's lamp, different skin conditions can be displayed in different colors, helping to analyze skin

    health more accurately and providing a scientific basis for skin care and treatment.

  • Parameters

    Product Name

    Medical Wood’s Lamp

    Product Model

    Z1310-F

    Light Source

    LED UVA

    Wavelength

    320-400nm(Peak:365nm)

    Visual Lens Diameter

    50*50mm

    Work Distance

    10-12cm

    Magnification

    1.5 times

    Power Supply

    Lithium Battery

    Application

    For Skin Disease Analysis


  • Instructions for Use:

    Woods lamp should be used in dark room!
    1.Clean the skin lesions;
    2.Turn on the device and warm up for 1 minute. Observe the lesion after the light source is stable.
    3.Hold woods lamp so that the light is aimed in the area of the lesion to be examined.
    4.Place the device about 10cm from the skin and adjust the device slightly up and down until a clear observation is obtained.
    5.Look through the lens with your eyes placed about 25~50mm above the device.
    6.Press the power button to turn off the device!
